Cylindrical Shape Piezoelectric Effect Crystals Langasite La3Ga5SiO14 LGS

  • 1
  • 2
  • 3

Brand Name : Crystro

Model Number : CR190107-6

Certification : SGS

Place of Origin : China

MOQ : 1pc

Price : Negotiable

Payment Terms : T/T, Western Union, MoneyGram, Paypal

Supply Ability : 2000pcs per month

Delivery Time : 2-4 weeks

Packaging Details : Transparent clean box

Type : Boule/Rod/Flats

Diameter : 50mm /60mm

Length : 10mm/5mm

Polish : 10/5 ,20/10

model : CR190107-6

certification : SGS

Contact Now

Piezoelectric Langasite La3Ga5SiO14 (LGS) Crystal Can be Customized



Lanthanum gallium silicate ( La2Ga5SiO14 ) is a phenomenal invention. Though langasite was initially developed as a laser crystal, it revealed a remarkable combination of piezoelectric qualities, which opened up new opportunities to use the LGS crystal in radio frequency devices. The main applications of langasite crystals now is SAW filters and SAW resonators. Experts agree that LGS is the best choice for high-efficiency broad band frequency devices because it possesses exceptional frequency-temperature characteristics, a very high index of electromechanical coupling and un unparalleled Q-factor.



Main Properties:



Crystal Structure  rigonal system, group 33 a= 8.1783 c = 5.1014
Growth Method  Czochralski
Hardness  6.6 Moh's
Density  5.754 g/cm3
Melt Point  1470 o C ( phase transition point: N/A)
Thermal expansion (x10-6/ oC)  α 11: 5.10 α 33: 3.61
Acoustic velocity, SAW  2400 ( m/sec )
Frequency constant, BAW  1380 ( kHz/mm )
Piezoelectric coupling  K2 (%) BAW: 2.21 SAW: 0.3
Inclusions  N0
